N.B: a Power Supply (sold separately) is needed to operate this charger.

The ToolkitRC M8P Charger is a small yet dependable option for charging FPV drones and cinematography equipment. Its touchscreen display allows for easy adjustment of charging settings, accommodating various XT60 battery models. Designed for portability, the M8P is a must-have for both drone enthusiasts and cinematography professionals.

SPECIFICATIONS:

- - Product size 100x71x34mm
  - Product weight 200g
- CHARGING
  - Input 7-35V: @MAX25A
  - Battery Type: LiPo LiHV LiFe Lion LTO @ 1-8S NiMh @1-20S Pb @1-12S
  - Charging Power: 600W @Max 20A
  - Discharging Power: 0.1-20A @ 600W Recycle External
  - Discharging Power: 0.1-3A @ 20W Normal mode
  - Balance current: 1000mA@4.2V
  - USB: 5.0V @ 2.1A upgrade
- MEASURING
  - PWM: 880us-2200us @20-400Hz
  - PPM: 880us-2200us*8Ch @20-50hz
  - SBUS: 880us-2200us*16ch @20-100Hz
  - Voltage: 1.0V-5.0V @1-8S
  - IR: 1-99mR @1-8S
  - ESC: 1-20A@1-35V MAX600W
- OUTPUT
  - PWM: 500us-2500us @20-1000Hz
  - PPM: 880us-2200us*8ch @50hz
  - SBUS: 880us-2200us*16ch @74Hz
  - Power: 1-20A @ 1-35V Mode: CC+CV
  - LCD Display: 2.4 IPS RGB 320x240 pixel

Features

600W DC Charger
1-8S Compatibility
XT60 Connector

Package Includes:

1 x ToolkitRC M8P 1-8S 600W 20A DC Battery Charger - XT60

ToolkitRC M8P 1-8S 600W 20A DC Battery Charger - XT60
